| MODEL NO. | FY1262000 | |||||||
| OUTPUT VOLTAGE | 12.6V | |||||||
| OUTPUT CURRENT | 2A | |||||||
| OUTPUT POWER | 25.2W | |||||||
| Features | ||||||||
| ·Universal AC input / Full range | ||||||||
| ·Plastic or metal case optional | ||||||||
| ·Cooling by free air convection | ||||||||
| ·regulated output with low ripple noise | ||||||||
| ·4 hours full load aging test | ||||||||
| ·Modified and customized design are accepted | ||||||||
| ·Certification:UL,ETL,CUL,GS,CE,UKCA,SAA,KC,PSE,CB,FCC,EMC,RoHS,REACH | ||||||||
| Quantity: | |
|---|---|
Product Description
| SPECIFICATION | |||||||||||
| OUTPUT | MODEL NO. | FY1262000 | FY1263000 | FY1264000 | FY1265000 | FY1266000 | FY1268000 | FY12610000 | FY12620000 | ||
| OUTPUT VOLTAGE | 12.6V | 12.6V | 12.6V | 12.6V | 12.6V | 12.6V | 12.6V | 12.6V | |||
| OUTPUT CURRENT | 2A | 3A | 4A | 5A | 6A | 8A | 10A | 20A | |||
| OUTPUT POWER | 25.2W | 37.8W | 50.4W | 63.0W | 75.6W | 100.8W | 126.0W | 252.0W | |||
| RIPPLE & NOISE (Max.) | 126mVp-p | 126mVp-p | 126mVp-p | 126mVp-p | 126mVp-p | 126mVp-p | 126mVp-p | 126mVp-p | |||
| INPUT | VOLTAGE RANGE | 100-240VAC~50/60Hz | |||||||||
| NO LOAD POWER (Max.) | 0.5W Max. | 1.8W | |||||||||
| LOADING POWER (Max.) | 29.3W | 43.4W | 57.9W | 72.4W | 85.9W | 114.5W | 140.0W | 273.9W | |||
| EFFICIENCY (Min.) | 86% | 87% | 87% | 87% | 88% | 88% | 90% | 92% | |||
| SIZE | DIMENSION(MM) | 113*43.5*30 | 113*43.5*30 | 113*43.5*30 | 133*58*31 | 133*58*31 | 154*60*36 | 178*80*38 | 233*110*70 | ||
| PROTECTION | OVER CURRENT | ≦2.2A | ≦3.3A | ≦4.4A | ≦5.5A | ≦6.6A | ≦8.8A | ≦11.0A | ≦22.0A | ||
| SHORT CIRCUIT | Capable of withstanding continuous short circuit and recover automatically. | ||||||||||
| OVER VOLTAGE | Output voltage shall not exceed 13.9V under single component fails conditions. | ||||||||||
| OVER TEMPERATURE | Once the internal temperrature reach to 95℃, the output current will drop automatically. | ||||||||||
| REVERSE POLARITY | [Optional] When the output polarity is reversed, the charger does not work and there is no output. | ||||||||||
| FULLY CHARGED SHUTDOWN | [Optional] When the battery is fully charged (charger indicator light turns green), the charger will turn off automatically. | ||||||||||
| ANTI-SPARK | [Optional] There is no spark generated when connecting the charger | ||||||||||
| SAFETY & EMC | SAFETY STANDARDS | UL1012 & IEC 60335 & EN60335 & AS60335 & J60335 & KC60335 | |||||||||
| EMI | CISPR22 CLASS | ||||||||||
| PRODUCT RELIABILITY | MTBF | 30000 hours for full rated load operation at 25 ℃ | |||||||||
| WARRANTY | 3 YEARS | ||||||||||
| TEMPERATURE RISING | 65 ℃ Max. at an ambient temperature of 25 ℃ | ||||||||||
| DIELECTRIC WITHSTAND TEST | 5mA 300VAC for 1 minute between input and output, input and housing. When choosing to increase the withstand voltage by 5%, the application time should be 3 seconds. | ||||||||||
| OPERATING AMBIENT TEMPERATURE RANGE | -29℃ TO +35 ℃ | ||||||||||
| STORAGE AMBIENT TEMPERATURE RANGE | -40℃ TO +75 ℃ | ||||||||||
| STORAGE HUMIDITY | 20% TO 65% RH | ||||||||||
| CONNECTOR | PLUG | 5521, 5525, RCA, XLR, XT60, M16, C14, etc./ Customized | |||||||||
| CABLE | UL2464 18# 1M length / Customizable | ||||||||||
Our 12.6V 2A lithium battery charger is a high-efficiency, reliable desktop charger designed to meet your charging needs. Its advanced intelligent charging technology ensures the safety and stability of the charging process, while multiple protections such as overcurrent, overvoltage, and short circuit protection guarantee the safety and reliability of your devices during charging. Crafted with high-quality materials and precision manufacturing, our product ensures durability and long-term stability.
Power Tools: Provides stable, fast charging for power tools such as drills and electric screwdrivers.
Portable Lighting Devices: Offers a convenient charging solution for outdoor lighting fixtures, camping lanterns, and more.
Portable Audio Devices: Supports long-term use of devices such as Bluetooth speakers and portable amplifiers.
Portable Electronic Devices: Ideal for charging portable electronic devices like smartwatches and wireless headphones.
Drones and RC Models: Provides a quick, convenient charging solution for enthusiasts of various remote-controlled models.
Wireless Camera Equipment: Ensures stable charging support for surveillance cameras, action cameras, and more.
Portable Medical Devices: Meets the charging needs of portable medical devices such as blood pressure monitors and glucose meters.
Mobile Office Equipment: Offers reliable backup power support for laptops, tablets, and other mobile office devices.
We offer personalized customization services to tailor charger products to specific specifications and requirements. Whether it's customizing appearance, adding specific functions, or adapting to special equipment, we provide professional solutions. Through our customization services, you can obtain charger products that fully meet your needs, providing the best power solution for your applications. Contact our sales team to learn more about the details and process of customization services.
